- Color: Black
- Angle: 60°
- Length of the struth: 38cm
- Working temperature: -40 až 85°C
- Protection: IP68
- Dimensions: 9,8 x 5cm (D x Š)
- Diametral of the screw: Circle 19mm / Square 15x15mm
VHF Part:
- Frequency bend VHF 146-174MHz
- Profit: 3dBi
- max.performance: 20W
- VSWR: TX < 2:1 / BW 2MHz
- Length of the cable: 5m (RG58)
- Connector of the radio: FME [Female]
- Connector of the antenna: FAKRA [Male] Cable 14cm)
GPS Part
- Frequency bend GPS: 1575,42 (+/-1,023)MHz
- Photom Power: 3-5V
- Profit: >27dBi
- Ampere: max.30mA
- VSWR: < 2:1
- Length of the cable: 5m
- Connector of the GPS device: SMB [Female]
- Connector of the antenna: RAST (Cable 20cm)
GSM Part:
- Frequency bend GSM: 890-860MHz / 1710-1880MHz
- VSWR: TX: < 1,5:1 / RX: < 2:1
- Performance: 4W
- Length of the antenna cable: 5m
- Connector of the GSM device: FME [Female]
- Connector of the antenna: RAST (Cable 20cm)
