Weight: 0,20kg
OE number: Camera2
Specification:
|
Image Sensors
|
1/3"for CCD color |
|
TV System
|
NTSC/PAL(NTSC as default,If you want Pal system,
please note it)
|
|
Effective Pixels
|
728X582/728x512
|
|
Sensing Area (mm)
|
3.3 x 2.6 |
|
Resolution (TV Lines)
|
600
|
|
Minimum illumination
|
<0.1 Lux / F1.2
|
|
Horizontal Sync.Frequency
|
15.625 KHZ |
|
Vertical Sync.Frequency
|
50 HZ |
|
Video Output
|
1.0Vp-P75 Ohm |
|
AGC
|
Auto |
|
BLC
|
Auto
|
|
Night Vision
|
Yes
|
|
IP Rating
|
ip67~68
|
|
S/N ratio
|
Better than 48dB
|
|
Lens
|
F=1.8
|
|
Lens Angle (Deg.)
|
wide angle 170 (Diagonal angle)
|
|
Current Consumption (mA)
|
85~115
|
|
Power Supply (DC V)
|
12V |
|
Operating
Temperature (Deg.C)
|
-20~+75(RH95% Max.) |
|
Storage Temperatur(Deg.C)
|
-40~+85(RH95% Max.) |
