Rear View CCD Camera for Ford Kuga, S-Max, Mondeo, Focus 2 Facelift

Image sensors

1/4" color CCD

TV system:

NTSC

Effective pixels:

728x512 Pixels

Resolution :

480TV lines

Electronic Shutter

1/60(NTSC)-1/10000S, 1/50(PAL)-1/10000S

Minimum illumination:

<0.1

Lens Angle:

160°

Waterproof:

IP68

Video output:

RCA connector, 1.0Vp-p, 75ohm

S/N ratio

Better Than 48db

Current Consumption:

60mA

Power supply:

DC 12V

Operating Temperature:

-20°C~ 80°C, RH95% Max.

Storage temperature:

-30°C ~ 80°C, RH90% Max.

Video cable length:

6m

Power supply cable length:

1.5m
