2 21 826 CMOS Parking Camera VW Crafter II. (2017->)

CMOS Parking Camera VW Crafter II. (2017->)

OE number: 2 21 826

Weight: 0.5 kg

Manufacturer: G-Park

CMOS parking camera integrated in the third brake light installed in the rear wing door.

Suitable for cars:
VW Crafter II. (2017->)

Technical properties:
- CMOS 1/3" sensor chip
- IR lighting with 6 LEDs (night vision)
- the possibility of setting the angle of view: +/-20°
- option to display guide lines (optional function)
- TV system: NTSC
- video output: 1.0V /75Ohm
- scanning angle: 170°
- weather protection: IP69K
- resistance to withdrawals: 10G
- camera connector: 4 pin screw
- connector on the monitor side: CINCH (RCA)
- cable length: 6.5 m
- number of scanning pixels: 762x504
- horizontal resolution: 700 TV lines
- white balance: automatic
- minimum lighting: 0LUX (illumination by infrared LEDs)
- signal/noise ratio: >48dB
- electronic aperture: 1/60 to 1/100000 sec.
- power consumption: <3W
- supply voltage: 12V
- working temperature from -30°C to +70°C

Installation in a car:
The camera is integrated on the third brake light located above the rear door. The light signaling of the brake light is ensured by the original light.

Function
NTSC TV standard
CMOS sensor
